Main application: electron beam welding of automobile transmission gears.

Main specifications and models:

（1）EBW-GE Single station Gear Electron Beam Welder

（2）EBW-MG multi station (three station/four station/six station, etc.) gear electron beam welder

（3）EBW-GTD type electron beam welder for planetary gear carrier. It can realize the welding of end face circle and horizontal circle (circumferential) weld.

   Electron beam power：4kW

   Acceleration voltage：60kV

   Vacuum degree of welding chamber：7×10-2 Pa

   Welding chamber volume：500×360×360 mm3

                                       （500×400×400 mm3）

   Scanning system: raster, circle, etc

   Tooling transmission system: with X and Y workbenches; With Z, X rotary table

   PLC control: logic program control, data acquisition, storage and printing

Main features: high production efficiency and cost-effective.

Main typical applications：

（1）Electron Beam Welding of Turbine Assembly of Hydraulic Torque Converter on Shanghai General BUICK Car

（2）Electron beam forming welding of the cockpit module beam of Shanghai Volkswagen POLO and TORAN commercial vehicles

（3）Electron beam penetration welding of silicone oil shock absorber

（4）Electron beam sealing welding of 24 station automobile air conditioner piston

（5）Double gun sliding seal electron beam continuous welding production line
